Three Phase Simplex Pump Control Panel, 208/240/480V, NEMA 4X, UL Listed
The Sasquatch SAS-S-3PH is a three phase control panel designed for use with one pump, rated for 208/240/480 VAC up to 32 FLA. Standard features include: NEMA 4X enclosure, motor and control circuit breaker(s), pump run light, alarm buzzer, 360-degree red beacon alarm light, and three mechanical floats. This control panel is UL listed and comes standard with two-year limited warranty.
Features
- NEMA 4X enclosure: 16”x 14”x 8”
- 208/240/480V, three phase, 1.0-32.0 FLA
- Motor protective switch: Branch circuit protection and adjustable overload
- Control circuit breaker
- Multi-tap transformer for easy panel configuration
- Pump hand-off-auto toggle switch
- Pump run light
- Alarm test and silence button
- 360-degree red beacon alarm light
- Alarm buzzer 85 decibels at 10’
- Includes three normally open mechanical floats with 20’ leads
- UL listed with two-year limited warranty
Original: $947.10
-70%$947.10
$284.13Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The Sasquatch SAS-S-3PH is a three phase control panel designed for use with one pump, rated for 208/240/480 VAC up to 32 FLA. Standard features include: NEMA 4X enclosure, motor and control circuit breaker(s), pump run light, alarm buzzer, 360-degree red beacon alarm light, and three mechanical floats. This control panel is UL listed and comes standard with two-year limited warranty.
Features
- NEMA 4X enclosure: 16”x 14”x 8”
- 208/240/480V, three phase, 1.0-32.0 FLA
- Motor protective switch: Branch circuit protection and adjustable overload
- Control circuit breaker
- Multi-tap transformer for easy panel configuration
- Pump hand-off-auto toggle switch
- Pump run light
- Alarm test and silence button
- 360-degree red beacon alarm light
- Alarm buzzer 85 decibels at 10’
- Includes three normally open mechanical floats with 20’ leads
- UL listed with two-year limited warranty
